Modeling and Measurement of Rebar Corrosion on Crack Formation Using High Frequency Ultrasonics in Three Dimensions and with No Contact with The Sample


Pierre-Phillipe Beaujean
Department of Ocean and Mechanical Engineering
Florida Atlantic University


The goal of this project is to demonstrate the ability to detect early appearance of cracks in reinforced concrete due to rebar corrosion, using ultrasonic nondestructive acoustic testing with no direct contact between the sensor and the concrete block, in conjunction with a poro-elastic ultrasound propagation model.  The objectives are threefold: (1) Identify the proper measurement configuration and predict the performance, using the modeling of the ultrasound propagation in the reinforced concrete; (2) Perform a series of targeted measurements using the proper ultrasonic transducers on a set of existing reinforced concrete samples placed in partial or complete immersion; (3) Evaluate the degree of corrosion within the reinforced concrete with confidence levels according to the poro-elastic model, and correlate the results with those obtained (separately from this proposal) using traditional non-invasive techniques (e.g. corrosion current and corrosion potential measurements).

The proposed poro-elastic model ties the physical properties of the porous medium (such as porosity, mean grain diameter, mass density, bulk modulus, shear modulus) to the sound propagation through the porous medium.  It can also handle gradual changes of the physical characteristics of the medium and produce a synthetic response to a broadband acoustic impulse.  This technique is very relevant in the material observed around the corroding bar.

This research would be the foundation for a more detailed acoustic analysis of rebar corrosion detection in reinforced concrete pilings/columns out in the field.

More Detail


Pierre-Philippe J. Beaujean

Pierre-Philippe J. Beaujean received the Ph.D. degree in ocean engineering from Florida Atlantic University in 2001. He is a Professor at the Department of Ocean and Mechanical Engineering, Florida Atlantic University. He specializes in the field of underwater acoustics, signal processing, sonar design, data analysis, machine health monitoring, and vibrations control. Dr. Beaujean is an active member of the Acoustical Society of America (ASA), and of the Institute of Electrical and Electronic Engineers (IEEE).
